In a recent article published in Nature Nanotechnology, researchers introduced an approach in single-molecule spectroscopy, significantly improving the ability to probe quantum transitions in individual molecules. Using controlled single-electron tunneling, the team aimed to map the spin states of molecules to their charge states, offering valuable insights into the energy levels of both ground and excited states.
Image Credit: Konstantin Kolosov/Shutterstock.com
Background
Exploring the electronic properties of individual molecules is crucial for advancing organic electronics, photonics, and molecular sensing. Traditional spectroscopy often struggles to resolve the intricate transitions of single molecules, limiting the understanding of their fundamental behaviors.
Single-molecule spectroscopy has emerged as a solution, allowing for detailed study at the molecular level. However, existing methods typically only capture a limited set of transitions, complicating the assignment of specific measurements to distinct quantum states.
The introduction of controlled single-electron tunneling techniques represents a significant advancement in this field. By enabling precise manipulation of charge states and facilitating the observation of various electronic transitions, this approach promises to enhance our understanding of molecular behavior.
The Current Study
The experimental setup utilized a custom-built atomic force microscope (AFM) equipped with a qPlus sensor, designed to operate under ultrahigh vacuum conditions at low temperatures (approximately 5 K). Pentacene and Perylenetetracarboxylic Dianhydride (PTCDA) molecules were deposited onto a thick NaCl film (greater than 20 monolayers) on a silver (Ag(111)) substrate, which served to electrically isolate the molecules from the underlying metal.
Voltage pulses were applied to the Ag(111) substrate to facilitate controlled single-electron tunneling. The Fermi level of the AFM tip was used to tune the alignment of molecular electronic states. The qPlus sensor, featuring a high-frequency cantilever, was employed in frequency-modulation mode to detect shifts in resonance frequency, which correspond to changes in the tip-sample interaction.
The experimental protocol involved a series of voltage pulse sequences to induce tunneling events, allowing for monitoring charge state populations over time. The read-out process was synchronized with the application of gate voltage pulses, enabling precise timing for data acquisition. Frequency shifts during designated read-out intervals were analyzed to quantify the relative populations of different charge states.
Data analysis involved fitting the frequency shift data to extract the energy levels of the electronic states and their transitions. This methodology provided a comprehensive mapping of the electronic properties of individual molecules, allowing for the investigation of both radiative and non-radiative transitions, as well as charge-related processes. The results were validated through repeated measurements to ensure reproducibility and accuracy.
Results and Discussion
The single-molecule spectroscopy method successfully revealed the electronic transitions of pentacene and PTCDA on the NaCl/Ag(111) substrate. The energy-level diagrams indicated distinct charge states, including singlet, doublet, and triplet configurations, which were mapped through controlled single-electron tunneling events.
For pentacene, the spectroscopy revealed distinct transitions between the highest occupied molecular orbital (HOMO) and the lowest unoccupied molecular orbital (LUMO), with energy differences aligning well with theoretical predictions. The varying lifetimes of the excited states provided valuable insights into the dynamics of charge transfer processes. A notable finding was the significant effect of the gate voltage on the alignment of molecular energy states, enabling precise fine-tuning of the electronic properties.
In the case of PTCDA, the method elucidated the complex interplay between radiative and non-radiative transitions. The data revealed multiple electronic states, with specific transitions corresponding to charge state changes that were previously uncharacterized. The ability to isolate these transitions facilitated a deeper understanding of the mechanisms underlying STM-induced luminescence phenomena observed in prior studies.
Conclusion
The study marks a significant advancement in single-molecule spectroscopy, presenting a valuable method for probing the electronic properties of organic molecules. The researchers’ approach allows for precise control over single-electron tunneling, enabling the mapping of spin states to charge states and providing insights into energy levels.
This work enhances our understanding of molecular behavior and has important implications for optimizing organic electronic devices. The findings suggest the potential to inform future research in molecular electronics and photonics while emphasizing the need for further exploration of the method’s capabilities and applications across various fields.
Journal Reference
Sellies L., et al. (2024). Controlled single-electron transfer enables time-resolved excited-state spectroscopy of individual molecules. Nature Nanotechnology. DOI: 10.1038/s41565-024-01791-2, https://www.nature.com/articles/s41565-024-01791-2
