In a recent article published in Scientific Reports, researchers investigated the use of Bentonite Nanoclay to protect mortar in historic brick structures. The study explores the effectiveness of a Nano Spraying Technique (NST) in enhancing the durability and longevity of these buildings. By leveraging nanotechnology, the research aims to mitigate the challenges posed by moisture and other environmental factors that contribute to the deterioration of masonry materials.
Image Credit: Okaycm'Stocker/Shutterstock.com
Background
Historical buildings constructed with stone and brick are particularly vulnerable to damage from humidity and environmental conditions. Degradation of the mortar, which binds these materials together, can compromise structural stability and aesthetic value.
Traditional preservation methods often fall short in providing adequate protection against these threats. Recent advancements in nanotechnology offer new ways to improve the properties of construction materials.
Nanoclay has shown potential in enhancing the mechanical and physical properties of various materials. This study builds on previous research to determine the optimal application of Bentonite Nanoclay for mortar preservation in historical buildings.
The Current Study
The researchers utilized a systematic approach to evaluate the impact of Bentonite Nanoclay on mortar samples. They tested various concentrations of nanoclay (2 %, 4 %, 6 %, and 10 %) using an NST, applying the solution in either one or two stages to ensure even distribution and penetration into the mortar matrix.
To analyze the results, Field Emission Scanning Electron Microscopy (FESEM) was conducted using the FESEM/SEM MIRA3 device. This technique allowed for detailed observation of the microstructural changes in the mortar, including the hole-filling rate of the nanoclay. The study assessed the effectiveness of different nanoclay concentrations and application methods in improving the resistance of the mortar to environmental factors such as moisture absorption and mechanical stress.
Results and Discussion
The findings revealed significant improvements in mortar properties treated with Bentonite Nanoclay. The application of a 4 % nanoclay solution in two spraying stages provided the most effective results. This method ensured better penetration of nanoclay particles, filling micro-cracks and voids within the mortar matrix more effectively than a single spraying application. SEM images demonstrated a marked reduction in visible holes and cracks in the samples treated with the optimal nanoclay concentration.
The study also emphasized the importance of the thickness of the sprayed layer. The two-stage spraying technique resulted in a thinner layer of nanoclay, facilitating deeper penetration and comprehensive coverage of the mortar surface. This enhanced coverage contributed to improved resistance against moisture absorption, thereby mitigating the risk of deterioration due to environmental exposure.
The research explored the broader implications of these findings for the conservation of historic buildings. The use of nanotechnology, specifically Bentonite Nanoclay, offers the potential to develop more effective preservation strategies that protect both the structural integrity and aesthetic qualities of masonry. This approach aligns with modern preservation methods and highlights the potential of Bentonite Nanoclay as a sustainable and innovative solution for heritage conservation.
Conclusion
The study demonstrated the effectiveness of Bentonite Nanoclay in enhancing the durability of mortar in historical brick constructions. The NST emerged as a viable method for improving the protective qualities of mortar against environmental degradation.
The optimal application of 4 % nanoclay in two stages significantly improved the microstructural integrity of the mortar, underscoring the potential of nanotechnology in heritage conservation.
As the challenges of preserving historical buildings increase, this research provides valuable insights into innovative preservation methods. Utilizing nanoclay not only addresses immediate concerns related to moisture and structural stability but also opens avenues for future research into sustainable materials for building conservation.
This study contributes to the growing field of nanotechnology in architecture, emphasizing the need for modern solutions to safeguard cultural heritage for future generations.
For More: The Role of Sustainability in Construction
Journal Reference
Jalalifar S., et al. (2024). Impact of spraying commercial Bentonite Nanoclay on fortification of the mortar as Nano Sprying Technique (NST) in heritages and historical buildings. Scientific Reports. DOI: 10.1038/s41598-024-72414-y, https://www.nature.com/articles/s41598-024-72414-y
