In a recent article published in npj Advanced Manufacturing, researchers investigated the effects of incorporating titanium carbide (TiC) nanoparticles into aluminum alloy 7075, a material widely used in aerospace applications due to its high strength-to-weight ratio. This research aims to enhance the casting performance of AA7075 by utilizing TiC nanoparticles, thereby improving fluidity and surface quality during the manufacturing process.
Image Credit: Anucha Cheechang/Shutterstock.com
Background
Aluminum alloy 7075 is known for its exceptional mechanical properties, making it a preferred choice in the aerospace industry. However, its casting process is hindered by issues such as low fluidity and the tendency to develop defects like hot cracks. Previous studies have indicated that the addition of nanoparticles can significantly improve the properties of metal alloys by enhancing their microstructural characteristics and fluidity.
Specifically, TiC nanoparticles have been shown to promote better dispersion within the metal matrix, leading to refined grain structures and improved mechanical properties. The current research builds on these findings, exploring how varying concentrations of TiC nanoparticles influence the fluidity and overall quality of AA7075 during casting.
The Current Study
The experimental procedure began with the preparation of the AA7075 alloy, which consists of aluminum combined with zinc, magnesium, copper, and chromium. To prevent oxidation, the alloy was melted in a graphite crucible at a controlled temperature of 820 °C under an argon gas atmosphere.
TiC nanoparticles were introduced in two concentrations: 0.5 vol% and 1 vol%. A master nanocomposite containing 3.5 vol% TiC was synthesized using a molten salt-assisted method, which was then gradually mixed into the molten aluminum to achieve the desired concentrations.
The fluidity of the alloy was tested using a vacuum setup, where varying levels of vacuum pressure were applied to draw the molten metal into bent glass tubes. The distance traveled by the molten metal before solidification was measured to determine fluidity length. Additionally, microstructural analysis was conducted using scanning electron microscopy (SEM) to examine grain size and morphology, while surface roughness was assessed using a white light interferometer.
Results and Discussion
The results indicated a marked improvement in the fluidity of the AA7075 alloy with the addition of TiC nanoparticles. The alloy with 0.5 vol% TiC exhibited the highest fluidity performance across all tested vacuum pressures, demonstrating a significant increase in flow distance compared to the pure AA7075. Fluidity length increased by over 20 % at lower vacuum pressures and approached 40 % at higher pressures, highlighting the effectiveness of nanoparticle incorporation.
Microstructural analysis revealed that the addition of TiC nanoparticles led to a reduction in grain size, with the AA7075-0.5TiC and AA7075-1TiC samples showing decreases of 63 % and 75 %, respectively, compared to the pure alloy. This refinement in grain structure is attributed to the nanoparticles' ability to hinder grain growth during solidification, resulting in a finer and less dendritic crystal structure.
Surface quality assessments further supported the positive impact of TiC nanoparticles. The pure AA7075 sample exhibited significant voids and roughness, while the samples with TiC showed smoother and glossier surfaces. The average roughness values indicated a reduction of 27 % and 59 % for the 0.5 vol% and 1 vol% TiC samples, respectively.
These improvements in surface quality are crucial for applications requiring high precision and aesthetic appeal, such as aerospace components. The study also noted that the enhanced wettability of the molten alloy due to the presence of nanoparticles contributed to better filling of intricate mold designs, essential for producing complex geometries.
The findings align with previous research that demonstrated the benefits of nanoparticle addition in improving the fluidity and mechanical properties of aluminum alloys. The study's results suggest that incorporating TiC nanoparticles enhances the casting performance while addressing traditional processing challenges. The ability to achieve finer grain structures and improved surface quality opens new avenues for the application of this alloy in demanding environments.
Conclusion
The incorporation of TiC nanoparticles into aluminum alloy 7075 significantly enhances its casting performance by improving fluidity and surface quality. The study demonstrates that even small concentrations of TiC can lead to substantial improvements in microstructural characteristics, resulting in finer grain sizes and smoother surfaces.
These advancements are particularly relevant for the aerospace industry, where component integrity and precision are paramount. The research highlights the potential of nanotechnology to revolutionize traditional casting methods and pave the way for more efficient and reliable manufacturing processes.
Future work may explore the long-term performance of these nanocomposites in real-world applications and the scalability of the nanoparticle incorporation process for industrial use. Overall, this study contributes valuable insights into the role of nanoparticles in enhancing the properties of aluminum alloys, setting the stage for further innovations in advanced manufacturing.
Journal Reference
Chen GC., Reufsteck T.F., et al. (2024). Nanotechnology enabled casting of aluminum alloy 7075 turbines. npj Advanced Manufacturing 1, 6. DOI: 10.1038/s44334-024-00004-x, https://www.nature.com/articles/s44334-024-00004-x
