Xilinx Offers 20nm All Programmable Ultrascale Silicon Portfolio

Xilinx, Inc. today announced availability of its 20nm All Programmable UltraScale™ portfolio with product documentation and Vivado^® Design Suite support.

Xilinx shipped its first 20nm silicon in early November 2013, continuing to execute on an aggressive UltraScale device rollout. These devices deliver an ASIC-class advantage with the industry's only ASIC-class programmable architecture coupled with the Vivado ASIC-strength design suite and UltraFast™ design methodology.

The new Xilinx^® UltraScale product portfolio extends Xilinx's market leading Kintex^® and Virtex^® FPGA and 3D IC families, based on the UltraScale architecture and the superior gate density of TSMC's 20SoC process. UltraScale devices enable 1.5x to 2x realizable system performance and integration, and consume up to half the power, relative to currently available solutions. These devices deliver next generation routing, ASIC-like clocking, and enhancements to logic and fabric to eliminate interconnect bottlenecks while supporting consistent device utilization of more than 90% without performance degradation.

"Xilinx continues to lead in technology innovation and ground breaking product offerings that enable fastest time to market," said Moshe Gavrielov, president and CEO at Xilinx. "UltraScale devices bring our customers ASIC-class capabilities by coupling our UltraScale ASIC-class architecture with our Vivado ASIC-strength design suite and UltraFast methodology. The combination of these silicon and design solutions enable the fastest path to achieve significant systems differentiation for our customers, and enables a far superior alternative to ASICs and ASSPs."

"Our collaboration with Xilinx has resulted in the development and deployment of many new technologies and methodologies," said TSMC President and Co-CEO, Dr. Mark Liu. "With the introduction of the first 20nm UltraScale Architecture products, Xilinx and TSMC demonstrate how the synergy between silicon process and device architecture extracts maximum product performance and results in the highest system value."

Kintex UltraScale Family

The new Kintex^® UltraScale™ FPGAs deliver up to 1.16M logic cells, 5,520 optimized DSP slices, 76 Mbits of BRAM, 16.3Gbps backplane-capable transceivers, PCIe^® Gen3 hard blocks, integrated 100Gb/s Ethernet MAC and 150Gb/s Interlaken IP Cores, and DDR4 memory interfaces. Initially introduced as part of the 28nm Xilinx 7 series family, Kintex devices established the new mid-range category of best price-performance at the lowest power. Kintex UltraScale devices are designed to continue leadership in this category to meet the requirements for the growing number of key applications including:

• 8K/4K Super High Vision Displays and Equipment
• 256-channel Ultrasound
• 8X8 Mixed Mode LTE and WCDMA radio with smart beamforming
• 100G Traffic Management/NIC
• DOCSIS 3.1 CMTS equipment

Virtex UltraScale Family

Also setting new industry standards, the new Virtex^® UltraScale™ devices provide unprecedented levels of performance, system integration and bandwidth on a single chip. The largest family member delivers 4.4M logic cells, 1,456 user I/Os, 48 x 16.3 Gb/s backplane-capable transceivers and 89 Mbits of Block RAM, breaking previous records by more than doubling Xilinx's industry's highest capacity Virtex-7 2000T device and delivering a staggering 50M equivalent ASIC gates. Virtex UltraScale devices include 28Gb/s backplane-capable and 33Gb/s chip-to-optics transceivers, in addition to integrated PCIe Gen3, 100Gb/s Ethernet MAC and 150Gb/s Interlaken IP cores, and DDR4 memory interfaces to support multi-hundred gigabit-per-second levels of system performance with smart processing at full line rates.

The system performance and capacity delivered with the Virtex UltraScale family makes these devices the logical choice for the most challenging applications such as:

• Single chip 400G MuxSAR
• 400G Transponder
• 400G MAC-to-Interlaken bridge
• Emulation and Prototyping

Xilinx^® UltraScale™ devices provide the same performance of the logic fabric and key architectural blocks across the entire UltraScale portfolio, enabling a scalable and optimized architecture. Moreover, with footprint compatibility between families, Kintex UltraScale FPGAs provide a clear migration path to Virtex UltraScale devices. To learn what Xilinx Alliance Program members are saying about the new UltraScale products, read quotes below.
