A group of researchers investigated existing technologies for dynamic windows in houses and automobiles in a new research paper reported in Nano Energy, concentrating on thermal radiation modification for heating and cooling management.
Study: Synergistic Modulation of Solar and Thermal Radiation in Dynamic Energy-Efficient Windows. Image Credit: onzon/Shutterstock.com
They examined infrared light from windows as a component of the internal heat input that may be continuously modified to improve efficiency even further. A new window that can successfully modify heat radiation based on the evaluation of a structure's energy-saving capabilities is suggested for use in renewable energy applications.
Benefits of Dynamic-Windows
Dynamic windows are more adapted to the environmental changes for reducing electrical loads than conventional energy-efficient approaches such as reflecting and faded glass. Because solar energy is the primary heat source throughout the day, contemporary dynamic windows, including thermal and mechanical responsive techniques, focus primarily on solar spectrum modification between 0.3 and 2.5 m.
Another substantial thermal exchange route via the window is infrared radiation, but the dynamic regulation in this region has received minimal attention.
In frigid winters, a lesser emission spectrum of the window promotes internal heat preservation by reducing mid-infrared radiation, but in hot summers, a greater emissivity promotes heat loss.
Although proactive temperature control techniques such as reduced emissivity windows and elevated coverings have resulted in significant energy savings in heating and cooling, they still have evident geographic limitations in terms of adjusting to changing environments.
Theoretical Analysis and Design Principle of Dynamic-Window
Existing windows have a constant emission rate, resulting in ineffective heat management when exposed to a dynamic environment. A dynamic window is developed by simulation analysis that can adjust solar and heat radiation, enabling the window to vary across heating and cooling phases.
When the weather turns hot, the dynamic windows in the cooling phase restrict radiation from the sun and release intense thermal radiation, whilst shifting to the heating phase in cooler temperatures can reduce radiative heat loss and allow the solar energy to heat the interior.
The dynamic window can adapt to changing weather for higher energy efficiency by using synchronous trends in solar transmittance instead of modifying trends.
Fabrication of Dynamic-Window
In this work, the mechanical strain was used to create the dynamic window switch, which is a simple solution with quick reaction and high reversibility when compared to electro- and thermo-responsive approaches.
A stretchy polydimethylsiloxane (PDMS) substrate (200 m) and a thin conducting poly (3,4-ethylene dioxythiophene) polystyrene sulfonate (PEDOT: PSS) coating (120 nm) were used to create a prototype of the mechano-responsive dynamic window. In comparison to conventional mechanochromic windows, the bilayer windows demonstrated higher overall performance.
The researchers employed an opaque film as a cover to reduce wrinkle interference, and solar transmittance to explore the effect of wrinkles and fractures in solar transmission modulation. The low-density fractures (20%) performed a minimal influence in solar modulation as the stress concentration gradually climbed to 50%.
When the opaque film was replaced with a transparent one and both the cracks and wrinkles were allowed to operate, solar transmittance increased from 95% to 14% when the tensile strain was raised to 50%. The creases were found to be the most important factor in the effective dynamic control of solar light.
Temperature Regulation of Dynamic Windows
The researchers constructed two similar compartments to test the dynamic windows' ability to regulate themselves on-site. To exclude sun radiation and remove ambient heat radiation, the exterior frames of the compartments were covered with aluminum foil.
The dynamic windows were installed on top of the chambers and were configured to release heating (0 % strain) and extended cooling (50% strain). The released state was very optically transparent, whereas the stretched state was opaque, and the thermal imaging revealed that the extended state was redder owing to increased emissivity.
Research Findings and Conclusion
The energy savings potential of emittance modulation of windows is studied in this research and a dynamic window that can adjust solar transparency and thermal emittance simultaneously is suggested.
A mechano-responsive multilayer window made of PDMS and PEDOT: PSS was produced as a prototype, which can control both solar and heat radiation via flexure sequence photonic structures.
According to wave optics simulations, the functions of generated wrinkles and fractures in the sequential structures were revealed, which may reduce solar transmittance and enhance heat emittance, respectively.
The dynamic window can manage the indoor temperature of the chamber up to 4 degrees Celsius, and prospective energy-saving analyses throughout the globe had established the dynamic window as a paradigm for improving building energy efficiency.
Continue reading: Could Nanoparticles Create Sustainable Lighting?
Reference
Zhou, Z. et al. (2021). Synergistic modulation of solar and thermal radiation in dynamic energy-efficient windows. Nano Energy. Available at: https://www.sciencedirect.com/science/article/abs/pii/S2211285521011149
