A study in Nature Communications describes a BiOCl-assisted chemical vapor deposition (CVD) technique for synthesizing ultrathin two-dimensional materials (2DMs) at significantly lower temperatures, ranging from 280 to 500 °C. This method aims to broaden the range of 2DMs that can be synthesized while maintaining compatibility with semiconductor manufacturing processes.
Image Credit: Marco de Benedictis/Shutterstock.com
Background
2DMs, such as graphene and transition metal dichalcogenides (TMDs), have unique electronic, optical, and mechanical properties due to their atomic-scale thickness. However, conventional synthesis methods often require high temperatures, limiting their integration with semiconductor technologies.
Lower-temperature synthesis techniques are needed to expand their applicability without compromising material quality. The use of BiOCl as a precursor lowers the volatilization temperature of metal precursors, enabling the growth of 2DMs at temperatures compatible with semiconductor fabrication.
The Current Study
The researchers used a BiOCl-assisted CVD method to synthesize 27 ultrathin 2DMs. The process started with preparing a precursor mixture containing BiOCl and metal salts specific to the desired 2DM. This mixture was placed in an alumina crucible and heated in a controlled inert atmosphere to prevent oxidation.
The growth temperature and duration were key factors in the synthesis process. Experiments were conducted at temperatures of 280 °C, 400 °C, and 500 °C, with growth times ranging from 1 to 20 minutes to optimize conditions for producing high-quality nanosheets.
The synthesized materials were analyzed using several techniques. Optical microscopy was used to observe the morphology of the nanosheets, and scanning electron microscopy (SEM) provided surface details. High-resolution transmission electron microscopy (HRTEM) examined the crystal structure, while X-ray photoelectron spectroscopy (XPS) determined the chemical composition. Raman spectroscopy identified the vibrational modes of the 2DMs, confirming their composition, and atomic force microscopy (AFM) measured nanosheet thickness.
To evaluate the electronic properties of the materials, field-effect transistors (FETs) were fabricated using e-beam lithography. These devices were tested under various conditions to assess their performance and potential for use in electronic applications.
Results and Discussion
The study synthesized a variety of ultrathin 2DMs, including SnS₂ and SnSe, demonstrating the versatility of the BiOCl-assisted CVD method. The results showed that growth temperature and duration significantly impacted the thickness and quality of the nanosheets, which ranged from a few nanometers to over 30 nanometers. For instance, nanosheets with an average thickness of 4.0 nm were produced at 600 °C after 5 minutes of growth, while extending the growth time to 20 minutes resulted in thicker sheets.
The optoelectronic properties of the synthesized materials were evaluated. FETs exhibited high mobility and on/off ratios, indicating their potential for electronic applications. Photodetectors made from these materials demonstrated high sensitivity to light, highlighting their suitability for optoelectronic devices.
The mechanisms driving the growth of 2DMs using the BiOCl precursor were also examined. BiOCl was found to create a stable growth environment, enabling uniform material deposition while reducing the risk of defects, a common issue in high-temperature processes. Comparisons with traditional high-temperature synthesis methods emphasized the advantages of the BiOCl-assisted approach, including reduced thermal stress on substrates and better compatibility with existing semiconductor fabrication processes.
Conclusion
This study demonstrates a BiOCl-assisted CVD method for synthesizing ultrathin 2DMs at low temperatures, offering precise control over thickness and quality. The materials exhibit promising electrical and optoelectronic properties, supporting applications in transistors, photodetectors, and other devices. The approach aligns with industry standards, enabling the integration of 2DMs into semiconductor technologies.
The findings provide a foundation for further exploration of low-temperature growth mechanisms and expand the material platform for advanced semiconductor applications. By reducing thermal requirements and improving material quality, this method contributes to the broader adoption of 2DMs in practical technologies.
Journal Reference
Qin B., Saeed M.Z., et al. (2023). General low-temperature growth of two-dimensional nanosheets from layered and nonlayered materials. Nature Communications. DOI: 10.1038/s41467-023-35983-6, https://www.nature.com/articles/s41467-023-35983-6?fromPaywallRec=false
