A recent study published in Advanced Energy and Sustainability Research investigated the synthesis and application of tungsten carbide nanoparticles embedded within carbon nanofoam composites to enhance electrocatalytic performance for hydrogen evolution.
Image Credit: U.P.SD/Shutterstock.com
Background
Hydrogen is a clean energy carrier with the potential to decarbonize heavy industries. Among various hydrogen production methods, water electrolysis is the most environmentally sustainable, but its efficiency depends on electrocatalysts that facilitate the hydrogen evolution reaction (HER) and oxygen evolution reaction (OER).
While platinum-based catalysts are highly effective, their high cost and limited availability drive the search for alternatives. Transition metal carbides, particularly tungsten carbide (WC), have emerged as promising candidates due to their strong catalytic activity and stability in acidic environments.
Material Synthesis and Characterization
The tungsten carbide–carbon nanofoam composites were synthesized using pulsed laser deposition (PLD). This process involved the simultaneous ablation of a tungsten-based target, containing both tungsten and tungsten carbide, and a graphite target.
Using this dual-target approach, the researchers created a hybrid material with tungsten carbide nanoparticles uniformly embedded within a carbon foam matrix. The deposition was performed at room temperature under carefully controlled conditions using a Q-switched Nd:YAG laser operating at a second harmonic wavelength of 532 nm.
To optimize composite formation, specific fluence levels and pressure conditions were maintained throughout the process.
Following deposition, the samples underwent an annealing treatment to promote carburization and crystallization, both essential for improving electrocatalytic performance. The resulting materials were then characterized using X-ray photoelectron spectroscopy (XPS), scanning electron microscopy (SEM), and X-ray diffraction (XRD) to analyze their morphology, composition, and crystallinity.
SEM imaging revealed a porous structure with a high surface area, while XPS confirmed the presence of both metallic and carburized tungsten phases. XRD data displayed clear peaks for tungsten carbide, with minimal oxidation observed even after prolonged electrochemical testing.
Results and Discussion
The synthesized composites demonstrated strong electrocatalytic performance for hydrogen evolution. The uniform distribution of tungsten carbide nanoparticles within the carbon nanofoam created an interconnected network that improved catalytic activity.
Electrochemical testing showed that the material achieved an overpotential of approximately 278 mV at a current density of 10 mA cm-2, along with exceptional stability over extended operation, making it a viable candidate for industrial applications.
The incorporation of tungsten carbide into the carbon foam matrix not only increased catalyst activity but also provided a stable framework that maintained structural integrity during prolonged use. The high surface area of the nanofoam facilitated greater interaction with the electrolyte, improving reaction kinetics and enhancing overall hydrogen evolution efficiency.
XPS analysis confirmed that the material retained both metallic and carburized tungsten phases, supporting its high electrocatalytic potential. These findings were further validated by XRD, which indicated that tungsten carbide remained stable with minimal oxidation, even after extensive electrochemical cycling.
The improved catalytic performance of the WC/carbon nanofoam composites can be attributed to multiple factors. Tungsten carbide provided more active sites than metallic tungsten, enhancing reaction rates. The high tungsten loading increased the availability of these catalytic sites, improving efficiency.
The conductive carbon nanofoam structure also supported the metallic phase and facilitated electron transfer, further enhancing hydrogen evolution activity.
Conclusion
This study highlights the potential of tungsten carbide–carbon nanofoam composites as cost-effective, high-performance electrocatalysts for hydrogen production. Their stability, scalability, and efficiency make them promising alternatives to platinum-based catalysts, supporting advancements in clean energy technologies and contributing to global decarbonization efforts.
What Is Tungsten Carbide Used For?
Journal Reference
Chaitoglou S., et al. (2025). Tungsten Carbide Nanoparticles Embedded in Carbon Nanofoam Composites for Efficient Electrocatalytic Hydrogen Evolution. Advances in Energy and Sustainability Research. DOI: 10.1002/aesr.202500016, https://advanced.onlinelibrary.wiley.com/doi/10.1002/aesr.202500016
