A recent article in Small addresses critical challenges in micro-packaging for neural implants.
Image Credit: Dana.S/Shutterstock.com
Background
A key challenge in developing next-generation neural implants is preventing material degradation when exposed to biological environments. Traditional materials often fail to maintain integrity, leading to device failure and potential adverse reactions.
As neuroscience and healthcare technologies advance, the demand for reliable packaging materials to ensure the longevity and efficiency of neural devices continues to grow. These miniature implants require robust solutions to maintain stability and functionality throughout their operational lifespan.
Atomic layer deposition (ALD) allows for precise control over film thickness and composition, producing coatings with excellent uniformity and mechanical properties. Hafnium-based ALD coatings, in particular, demonstrate strong biocompatibility and barrier capabilities, making them promising for medical use.
Parylene C, known for its excellent conformal coating properties, also holds potential. However, concerns about its stability in biological environments persist. To address these challenges, this study evaluates two multilayer coatings: an inorganic hafnium-based layer created through atomic layer deposition (ALD) and a hybrid organic-inorganic stack combining Parylene C with titanium-based ALD layers. The goal is to understand the biostability and protective performance of these coatings during prolonged in vivo exposure.
The Current Study
To thoroughly evaluate these coatings, researchers conducted a seven-month in vivo study using animal models. Silicon microchips with distinct surface microtopography were coated with either hafnium-based ALD layers or the Parylene C-titanium ALD hybrid. The samples were sterilized in isopropyl alcohol before implantation. Coated microchips were implanted subcutaneously and later explanted at intervals of two, four, and seven months to assess longitudinal performance.
The analysis included an evaluation of tissue responses around the implants using hematoxylin and eosin staining to observe inflammation and integration. Surface and structural integrity of the coatings were assessed using optical and cross-sectional scanning electron microscopy (SEM), while Time-of-Flight Secondary Ion Mass Spectrometry (ToF-SIMS) provided detailed insights into chemical stability and ionic penetration over time.
Results and Discussion
The study's findings provided significant insights into the biostability of the multilayer coatings after implantation. The hafnium-based ALD multilayer coatings demonstrated impressive resilience against ionic penetration, showcasing no evident degradation or alteration following the seven-month exposure to body fluids. This highlights the efficacy of the ALD process in creating robust micro-packaging solutions that can maintain functional stability over extended periods.
In contrast, the Parylene C and titanium-based ALD hybrid multilayer stack showed considerable degradation, particularly within the outer 70 nm layer of Parylene C. Microscopy examinations revealed surface degradation and ion ingress, suggesting that while the hybrid coating offers some protective benefits, it may not provide sufficient long-term stability in dynamic biological environments. The study highlights the need for careful material selection, particularly for applications that demand prolonged interaction with biological systems.
The results align with previous literature, which underscore the importance of material properties, coating methods, and the long-term performance of packaging solutions in biocompatible applications. While the hybrid multilayers display certain advantages, the hafnium-based ALD multilayer stands out as the superior option for micro-packaging neural implants. It effectively addresses long-term stability concerns, ensuring both device functionality and patient safety.
These findings emphasize the critical role of material science in improving implantable medical devices. By enhancing our understanding of how bio-implants interact with their environments, this research lays the groundwork for future advancements in neural device packaging aimed at optimizing both performance and durability.
Journal Reference
Nanbakhsh K., et al. (2025). An in vivo biostability evaluation of ALD and Parylene-ALD multilayers as micro-packaging solutions for small single-chip implants. Small. DOI: 10.1002/smll.202410141, https://onlinelibrary.wiley.com/doi/10.1002/smll.202410141
